L'anneau de levage male à tige longue bichromate ALLZB est fabriqué en acier C15 estampé avec une finition zingué bichromaté et un filetage ISO.
Cet anneau levage ALLZB est disponible du diamètre 6 au 45mm et des CMU 70kg à 6500kg.
La charge de rupture de l'anneau est obtenue en multipliant la CMU par le coefficient 6.
Référence | Diamètre | CMU [kg] | CMU à 45° [kg] | A [mm] | B [mm] | C[mm] | E [mm] | L [mm] | L1 [mm] | Pas métrique [mm] | Poids [kg] |
ALLZB106 | M 6 | 70 | 50 | 20 | 36 | 20.5 | 8 | 44 | 24 | 1 | 0.06 |
ALLZB108 | M 8 | 140 | 90 | 20 | 36 | 20.5 | 8 | 44 | 24 | 1.25 | 0.07 |
ALLZB110 | M 10 | 230 | 150 | 23 | 44 | 22.5 | 10.5 | 51 | 28.5 | 1.5 | 0.12 |
ALLZB112 | M 12 | 340 | 240 | 29 | 50 | 22.5 | 10.5 | 60.5 | 40 | 1.75 | 0.16 |
ALLZB114 | M 14 | 500 | 350 | 33 | 57 | 26 | 12 | 69.5 | 40 | 2 | 0.20 |
ALLZB116 | M 16 | 700 | 480 | 37 | 65 | 28 | 14 | 76 | 50 | 2 | 0.34 |
ALLZB118 | M 18 | 930 | 600 | 41 | 71 | 31 | 15 | 85 | 52 | 2.5 | 0.43 |
ALLZB122 | M 22 | 1500 | 1000 | 50 | 84 | 35 | 17 | 98 | 62 | 2.5 | 0.68 |
ALLZB124 | M 24 | 1800 | 1200 | 53 | 94 | 38 | 20.5 | 110 | 67 | 3 | 1 |
ALLZB127 | M 27 | 2500 | 1500 | 59 | 101 | 40 | 21 | 120 | 74 | 3 | 1.29 |
ALLZB130 | M 30 | 3150 | 2400 | 60 | 109 | 45.5 | 24.5 | 132 | 79 | 3.5 | 1.83 |
ALLZB133 | M 33 | 4000 | 3000 | 64 | 121 | 55 | 28.5 | 144 | 84 | 3.5 | 2.48 |
ALLZB136 | M 36 | 5000 | 3000 | 69 | 133.5 | 68.5 | 32.5 | 155 | 95 | 4 | 3.95 |
ALLZB139 | M 39 | 5500 | 3300 | 69 | 133.5 | 68.5 | 32.5 | 155 | 95 | 4 | 4.10 |
ALLZB142 | M 42 | 6000 | 3600 | 80 | 149.9 | 79.5 | 35.2 | 180 | 108 | 4.5 | 4.35 |
ALLZB145 | M 45 | 6500 | 3900 | 80 | 149.9 | 79.5 | 35.2 | 180 | 108 | 4.5 | 4.42 |
